Description
Performance Parameter Table
| Model | Ratio | Power | 50HZ | 60Hz | Cylinder(mm) | Weight(KG) | |||||
| phase | HP | Pole | Head (m) | Flow L/min | Head (m) | Flow L/min | |||||
| JKD | 40SK-1 | 1.1 | 3 | 1 | 2 | 13 | 250 | 14 | 260 | 50/40 | 29 |
| JKD | 40SK-2 | 1.1 | 3 | 2 | 2 | 16 | 320 | 20 | 350 | 50/40 | 38 |
| JKD | 40SK-3 | 1.1 | 3 | 3 | 2 | 21 | 385 | 25 | 420 | 50/40 | 41 |
| JKD | 50SK-3 | 1.1 | 3 | 3 | 2 | 23 | 430 | 23 | 510 | 65/50 | 41 |
| JKD | 50SK-5 | 1.1 | 3 | 5 | 2 | 26 | 520 | 30 | 560 | 65/50 | 55 |
| JKD | 65SK-5 | 1.1 | 3 | 5 | 2 | 27 | 550 | 29 | 620 | 65/50 | 55 |
| JKD | 65SK-7.5 | 1.1 | 3 | 7.5 | 2 | 32 | 730 | 35 | 920 | 80/65 | 95 |
| JKD | 65SK-10 | 1.1 | 3 | 10 | 2 | 34 | 760 | 38 | 1020 | 80/65 | 106 |
| JKD | 100SK-15 | 1.1 | 3 | 15 | 2 | 36 | 1700 | 39 | 1850 | 80/100 | 115 |
| JKD | 40SP-3 | 1.4 | 3 | 3 | 2 | 22 | 400 | 23 | 340 | 50/40 | 41 |
| JKD | 50SP-3 | 1.4 | 3 | 3 | 2 | 19 | 500 | 19 | 400 | 65/50 | 41 |
| JKD | 50SP-5 | 1.4 | 3 | 5 | 2 | 28 | 560 | 32 | 500 | 65/50 | 55 |
| JKD | 65SP-5 | 1.4 | 3 | 5 | 2 | 27 | 520 | 25 | 600 | 80/65 | 55 |
| JKD | 65SP-7.5 | 1.4 | 3 | 7.5 | 2 | 31 | 720 | 35 | 750 | 80/65 | 95 |
| JKD | 65SP-10 | 1.4 | 3 | 10 | 2 | 33 | 750 | 38 | 850 | 80/65 | 106 |
| JKD | 100SP-15 | 1.1 | 3 | 15 | 2 | 35 | 1630 | 35 | 1700 | 100/100 | 115 |
