Description
Technical Data:
| Model | Capacity (L/Min) | Head (m) | Power (Kw) | Rotation (RPM) | Diameter (mm) | Discharge | Material | Temperature | Viscosity(Cps) | Shaft |
| HD+AL | 165 | 10 | 800 | 10000 | 41 | 25 | AL | 100 | 1000 | SS304 |
| HD+AL-HP | 100 | 28 | 800 | 10000 | 41 | 25 | AL Alloy | 100 | 1200 | SS304 |
| HD+SS304 | 165 | 10 | 800 | 10000 | 42 | 25 | SS304 | 100 | 1000 | SS316L |
| HDSS304HP | 100 | 28 | 800 | 10000 | 42 | 25 | SS304 | 100 | 1200 | SS316L |
| HDSS316L | 165 | 10 | 800 | 10000 | 42 | 25 | SS316L | 100 | 1000 | SS316L |
| HDSS316LHP | 100 | 28 | 800 | 10000 | 42 | 25 | SS316L | 100 | 1200 | SS316L |
| HDPPHT | 165 | 10 | 800 | 10000 | 41 | 25 | PP | 80 | 1000 | SS316L |
| HDPPHT-HP | 100 | 28 | 800 | 10000 | 41 | 25 | PP | 80 | 1200 | HB |
| HD+PVDF | 165 | 10 | 800 | 10000 | 41 | 25 | PVDF | 100 | 1000 | HB |
| HDPVDF-HP | 100 | 28 | 800 | 10000 | 41 | 25 | PVDF | 100 | 1200 | HB |
| HD+PTFE | 165 | 10 | 800 | 10000 | 50 | 25 | PTFE | 130 | 1000 | HB |
| HDPTFE-HP | 100 | 28 | 800 | 10000 | 50 | 25 | PTFE | 130 | 1200 | HB |
Note:
1.The Motor is Common Speed control Motor
2.Voltage:220V,50Hz
